Project Description
Description
Mini Gps Tracking Pcb Single Sided Pcb And Single Sided Pcb Borad
Specs
I
|
Product Name
|
Custom PCB Printed Circuit Board
|
|
Type
|
PCB
|
|
Material
|
FR4, CEM1, CEM3, High Frequency Board,
|
|
Layer
|
1,2,4,6…20Layer
|
|
Shape
|
Rectangular, Round, Slots, Cutouts, Complex, Irregular
|
|
Cutting
|
Shear, V-score, Tab-routed
|
|
Copper Thickness
|
0.5-4oz, regular 1oz
|
|
Solder Mask
|
Green, Red, Blue, Yellow, etc.
|
|
Silk Screen
|
White, Black, etc.
|
|
Silk Screen Min Line Width
|
0.006″ or 0.15mm
|
|
Min Trace/Gap
|
0.1mm or 4mils
|
|
Min Drill Hole Diameter
|
0.01″,0.25mm or 10mils
|
|
Surface Finish
|
HASL, ENIG, OSP, etc.
|
|
|
Application
Home office, Factory, room
